Add Alarm Group

  • Description

    This interface is used for users to add alarm groups.

  • Request URL

    URL:[Host Server]/api/v2/alarm/group

  • Query Parameters

    Field Type Description
    Host Server string See Explanation of terms

  • Method

    PUT

  • Headers

    Field Type Description
    Authorization string "Bearer " + Access Token obtained from the login interface

  • Body

    Field Type Description
    boxId string FGate id
    name string "Alarm Group Name," within 20 characters.
    memo string "Alarm Group Remarks"
    cuids list "Collection of Alarm Contact IDs (if no alarm contacts, pass an empty array)."

  • Response Success

    NULL

  • Response Codes

    Field Description
    401 Access Token Expired
    404 This name has already existed.
    409 Alarm Contact Does Not Exist
    400 Error message in the HTTP header[X-FBox-Code], see Appendix Three for details.
    500 "Invalid Parameters"

  • Postman example is as follows:

Login Interface

  • Please see the example in the following image.

Login Interface
